| Brand Name: | Dimax |
| Model Number: | 100side-hinged window |
| MOQ: | 1 |
| Price: | 1000-1200 |
| Delivery Time: | 45 |
| Payment Terms: | L/C,T/T |
100 Series Side-Hinged Window: Flexible Lateral Swing for Enhanced Ventilation & Easy Maintenance
INFORMATION
| Brand | Dimax |
| Material | 6063-T5 |
| Thickness | 2.0mm |
| Bearing | 60kg |
| Blade width | 600-800mm |
| Blade height | 600-1600mm |
| Certification | NFRC, CSA, CE, |
| Glass | Single-pane glass, laminated glass, double-layer tempered glass, tempered laminated glass, triple-layer tempered glass |
| Powder-coat | Interpon, Dulux (warranty treatment 10/20 years) |
| Hardware | KIN LONG,BONWAY,ROTO and so on |
| Configuration | A. AA. A/F or customized design |
| Heat Insulation | UW1.5W/㎡K |
| soundlnsulafion | Rw up to 37dB |
| Ufimate Wind Pressure | +3000pa |
| Water Resistance | +720Pa |
The 100 Series Side-Hinged Window utilizes a side-pivot rotating structure, allowing the sash to open horizontally up to 180 degrees and remain securely positioned at any angle, facilitating two-sided cleaning and serving as an emergency escape passage when needed. The frame is equipped with reinforced stainless steel hinge load-bearing systems and multi-point interlocking locks, combined with a triple-compression sealing design, achieving the highest national standard of Level 9 wind pressure resistance. The profiles feature wide-chamber thermally broken aluminum with injected thermal barrier technology, paired with adjustable ventilators and Low-E insulating glass, resulting in a whole-window thermal transfer coefficient as low as 1.4 W/(m²·K). Optional accessories include concealed stainless steel mesh screens, motorized opening/closing mechanisms, and rain-sensing smart modules, making it suitable for hospitals, schools, hotels, and renovation projects in older buildings where integrated demands for ventilation efficiency, safety protection, and energy performance are critical.
