| Brand Name: | Dimax |
| Model Number: | 80 series Swing Door |
| MOQ: | 1 |
| Price: | 1000-1200rmb |
| Delivery Time: | 45 |
| Payment Terms: | L/C,T/T |
80 Series Swing Door: Precision-Hinged Design for Seamless Indoor-Outdoor Transition
INFORMATION
| Brand | Dimax |
| Material | 6063-T5 |
| Thickness | 2.0mm |
| Bearing | 150kg |
| Blade width | 600-1300mm |
| Blade height | 1500-3500mm |
| Certification | NFRC, CSA, CE, |
| Glass | Single-pane glass, laminated glass, double-layer tempered glass, tempered laminated glass, triple-layer tempered glass |
| Powder-coat | Interpon, Dulux (warranty treatment 10/20 years) |
| Hardware | KIN LONG,BONWAY,ROTO and so on |
| Configuration | A. AA. A/F or customized design |
| Heat Insulation | UW1.4W/㎡K |
| soundlnsulafion | Rw up to 37dB |
| Ufimate Wind Pressure | +5040pa |
| Water Resistance | +1050Pa |
The 80 Series Swing Door features reinforced heavy-duty hinge construction and a multi-layer sealing system, delivering smooth, silent operation and comprehensive weather protection. Its expansive glass design and narrow-frame structure maximize natural light intake, while energy efficiency is enhanced through thermal-break profiles and low-emissivity glazing. Configurable for inward or outward opening, the door can be equipped with impact-resistant base frames and multi-point locking systems to suit high-traffic commercial entrances, residential balconies, and premium office spaces. Surface finishes utilize weather-resistant coating technology, combined with customizable dimensions and opening modes, achieving an optimal balance of functional durability and contemporary aesthetics.
